The water of the aquarium is directed in a thin stream past a UV-C compact lamp housed in a special watertight casing in the JBL AquaCristal UV-C water clarifier. The UV-C rays penetrate the flow of water and kill algae cells as well as bacteria and other germs, successfully eliminating any cloudiness caused by bacteria and floating algae. Since the level of germs in the water is kept to a minimum and the incidence of infection is reduced, the germicidal effect also promotes the health of the fish. The actual physical treatment method itself, using radiation, does not alter the water values in any way and has no negative effect on the cleansing bacteria in the filter which play a vital role in breaking down pollutants.The JBL AquaCristal UV-C water clarifier successfully removes cloudiness caused by floating algae or bacteria.
Reduces the number of disease-carrying germs in the water, promoting the health of the fish.
No detrimental effect on cleansing bacteria in filter.
With exchangeable connecting sockets fitting all sizes of hoses.
Highly effective by reflecting the radiation on the white inner wall of the casing. Casing made of robust, UV-resistant and saltwater-resistant plastic.
Inlet and outlet on the same side, saving space when installing.
Safety factor: UV-C burner automatically switches off when unit is opened.
Extra long cable: 2 m to ballast control and 5 m from ballast control to UV-C unit.
Operates on the physical principle of rays. The quality of the water is not altered by chemical additives etc.
Here you will find more informations to the JBL UV units.
Application at the aquarium: Cloudiness: for 200-400 l content flow rate 100-200 l/h partial germ destruction: for 20-100 l content flow rate 50-100 l/h
Application at the pond: Cloudiness: for 3000-5000 l content flow rate 500-1000 l/h partial germ destruction: for 300-500 l content flow rate 100-200 l/h
technical data JBL AquaCristal UV-C 5 W:
Length: 21 cm
UV-C radiation: ca. 255 nm
Power: 5 W
Socket: G23
new version -Series II
JBL AquaCristal UV-C 5 W Series II
